10000 Gallon Stainless Storage Tank

10,000–gallon (10,400) gallon vertical 304 polished sanitary stainless steel cone bottom storage tank manufactured by JV Northwest in 1992 has a MFG’s Serial No:11404.

• Tank measures 10’-3” in diameter X 16’-0” high on the straight side with 16” or 15˚ deep conical bottom & top (20’-10” OAH).
• All internal welds have been ground smooth & polished.
• Bottom cone has a 3” sanitary drain fitting and is elevated 12” from grade to bottom of fitting.
• There is a 16” X 22” side manway with a swing out cover and a 6”-150 LB mixer support flange on side.
• Tank is supported with six 6” stainless steel pipe legs that are encased in concrete with adjustable base plates and has assorted fittings for plumbing.
• 2 Available
